1. Core Technical Parameters

Supply Input：5 VDC

Internal Bus：Controlway Bus

Max Connected Nodes：16

Transmission Baudrate：500 kbaud

Isolation Withstand：1500 VDC

Operating Ambient Temp：0℃ ~ +70℃

Applicable Rack：ABB Symphony INFI90 Harmony chassis

2. Compatibility & Expandability

Same-brand Compatibility

ABB INNIS11 is a compact bus slave interface card tailored for ABB Symphony DCS control racks. On-site instrumentation technicians install multiple ABB INNIS11 on cabinet backplanes to extend bus access channels for small-scale workshop control loops. ABB INNIS11 slides into standard single-width rack slots and exchanges process data with ABB INNPM12 network processors and all series analog/digital I/O modules without extra conversion terminal boards. Front-panel rotary coding switches support manual station setup to keep ABB INNIS11 running stable data transmission with all factory-deployed ABB temperature and pressure transmitters.

Cross-brand Compatibility

Proprietary Controlway bus communication protocol prevents direct hardware docking of ABB INNIS11 with third-party main controllers. Independent protocol translation gateways become necessary to build data links connecting ABB INNIS11 to PLC equipment from Siemens or Schneider. Universal serial signal conversion logic enables ABB INNIS11 to forward field measurement data to most aftermarket monitoring screens with no internal circuit refitting.

3. Lifecycle Cost Analysis

Service cycle of ABB INNIS11 lasts 10 years, exchange rate:1USD=7.2CNY, purchase and installation fees are excluded from all cost calculation

Annual routine maintenance cost: Bus signal inspection and internal dust cleaning for ABB INNIS11 costs 30 USD per year, total 10-year maintenance expense: 300 USD

Spare part replacement cost: Bus interface chip failure of ABB INNIS11 generally occurs once every 8 years, single spare module price: 405 USD, total replacement expense within 10 years: 405 USD

Retrofit expense saving: Original rack wiring layout and slot structure fully match ABB INNIS11 during DCS cabinet upgrading, saving 246 USD extra construction labor cost compared with incompatible substitute interface modules

Total cumulative running cost for single ABB INNIS11 across ten service years: 459 USD
