1. Core Technical Parameters

Rated Supply：24 VDC

Terminal Count：20 screw signal terminals

Applicable Series：AC500 PLC I/O modules

Permitted Cable Gauge：0.4–2.5 mm²

Dielectric Withstand Voltage：2000 VAC

Operating Temperature：-20℃ ~ +60℃

Mounting Standard：DIN rail TS35

2. Compatibility & Expandability

Same-brand Compatibility

ABB TU515 is dedicated terminal base matched with ABB AC500 modular I/O hardware. Electrical installers arrange multiple ABB TU515 on cabinet DIN rails to gather discrete field wiring for packaging and logistics automation racks. ABB TU515 locks beneath AC500 digital and analog I/O modules and conducts signal transmission with ABB PM5 series CPU without extra intermediate terminal strips. Buckle-type mechanical fixation maintains stable signal contact when ABB TU515 operates alongside all original ABB pushbutton stations and contactor actuators.

Cross-brand Compatibility

Exclusive AC500 module bottom buckle structure stops direct assembly of ABB TU515 onto third-party PLC hardware. Separate signal transfer terminal adapters are required to build wiring links connecting ABB TU515 to Siemens and Schneider I/O modules. General screw wiring specifications allow ABB TU515 to connect standard 24V third-party proximity sensors with no structural refitting on ABB TU515.

3. Lifecycle Cost Analysis

Service cycle of ABB TU515 covers 10 years, exchange rate:1USD=7.2CNY, purchase and installation fees are excluded from all cost statistics

Annual routine maintenance cost: Terminal torque inspection and internal dust removal for ABB TU515 costs 16 USD per year, total 10-year maintenance expense: 160 USD

Spare part replacement cost: Spring terminal fatigue damage of ABB TU515 generally occurs once every 9 years, single spare terminal base price: 174 USD, total replacement expense within 10 years: 174 USD

Retrofit expense saving: Existing field signal cables fully fit ABB TU515 during cabinet upgrade reconstruction, saving 108 USD extra wiring labor cost compared with incompatible substitute terminal bases

Total cumulative running cost for single ABB TU515 across ten service years: 226 USD
